MJ-UQK-61 5m cable

UQK - 61 series is the use of floating ball float liquid level controller built-in micro switch signal contact of the liquid level controller, can apply to a variety of liquid level control.Because there were the external mechanism, particularly suitable for containing solid, semi-solid state of floating liquid, mucoid: the following water channel processing, factory waste water pool and other liquid tank liquid level automatic alarm and control.Controller by radioactive and earthquake resistance test and can be used for nuclear power plant level automatic alarm.Controller components in contact with the liquid materials are plastic, with good corrosion resistance.

The characteristics of
Low external without moving, won't produce floating debris stuck fault.
Suspension type field installation, especially suitable for the underground pool.
Low range, can free setting at the scene.
Using micro switch long service life, low price.
Low contact with the liquid parts are plastic material, has excellent corrosion resistance.

Dimension: float bits of 88 x 172, junction box, the largest diameter bits of 205, 142, installation of flange size: central circle diameter of bolt hole bits of 18, 170, 4 hole - bits of flange diameter bits of 205;
Low output signal: micro switch single pole double throw contact output/A1/2 HP 250 vac
Low contact life: 5 x 104
Low medium temperature: - 10 ℃ ~ + 55 ℃ IE level controller for - 10 ℃ ~ + 80 ℃
When the adjusting range is: 0.3 m to 4 m (6 meters, 13 meters, 20 meters, for IE level gauge)
Low main parts material: float: ABS plastic;Weight: carbon steel or cast iron outside protective lacquer;Suspension cable: nylon cord wire;Three core as a set of flexible cable (oil resistant styrene butadiene rubber) seismic requirements (IE level controller) : can withstand the qinshan phase ii nuclear power plant seismic response spectrum.
Low radioactive (IE level controller) : 2 x 10000 gy
